794617-6
Manufacturer:
TE Connectivity
Mfr.Part #:
794617-6
Datasheet:
Description:
Headers and Wire Housings Free Hanging Socket Number of Positions:6 Pitch:2.9972 mm
| Parameter | Value |
|---|---|
| Length | 10 mm |
| Width | 11.7 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 2 |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| Depth | 14.04 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.9972 mm |
| Current Rating | 5 A |
| Max Voltage Rating (DC) | 250 V |
| Flammability Rating | UL94 V-0 |
| Approvals | CSA |
| Orientation | Straight |
| Operating Supply Voltage | 250 V |
| Lifecycle Status | Production (Last Updated: 2 weeks ago) |
| Color | Black |
| Gender | Female |
| Number of Contacts | 6 |
| ELV | Compliant |
| Connector Type | Socket |
| Wire/Cable Gauge | 20 AWG |
| Number of Positions | 6 |
| Number of Rows | 2 |
| Row Spacing | 3 mm |
| Housing Material | Nylon |
| Fastening Type | Latch |
| Connector System | Wire-to-Board |
| Contact Style | Socket |
| Max Voltage Rating (AC) | 250 V |
| Housing Color | Black |
| Contact Gender | Female |
| VDE Tested | Yes |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
| Sealable | No |
| Contact Retention | Without |
Stock: 8082
Distributors
pcbx
pcbxUnit Price$0.31889
Ext.Price$0.31889
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.31889 | $0.31889 |
| 10 | $0.26161 | $2.61610 |
| 25 | $0.24366 | $6.09150 |
| 50 | $0.23716 | $11.85800 |
| 100 | $0.23083 | $23.08300 |
| 300 | $0.21722 | $65.16600 |
| 500 | $0.20441 | $102.20500 |
| 1000 | $0.19236 | $192.36000 |
